Other Rigging Components

PREMIUM MECHANICAL STEERING SYSTEMS

Y23 Helm (non self-
Y22 Helm (fast-connect centring fast-connect
system) system)

Y24 Helm/Bezel
Y12 Helm/Bezel Y24 Helm/Bezel

All these systems are highly responsive and are designed and Y10 COMPLETE KIT FOR ENGINES BELOW 40KW (OR
built to our exacting standards of safety, durability and comfort. BELOW 55HP) INCLUDING Y11, Y12 AND STEERING
The Y22 and Y23 helms (or Y20 kit) can be used for all types WHEEL YMM-24003-00-BK
of applications. Our Y23 helm has a special non self-centring
mechanism, which means the wheel won’t return automatically FEET CM Part Name Part Number
to the straight ahead position after a turn. Both these helms 8' 244 CABLE Y10 STEERING 8 YMM-22208-00-00
have to be installed with a Y25 Bezel, which is available in 20° 9' 274 CABLE Y10 STEERING 9 YMM-22209-00-00
and 90° versions. 10' 305 CABLE Y10 STEERING 10 YMM-22210-00-00
11' 335 CABLE Y10 STEERING 11 YMM-22211-00-00
Number of turns lock-to-lock: Y12 - approx 2.5 Y22/Y23 - 12' 366 CABLE Y10 STEERING 12 YMM-22212-00-00
approx 3.8 Y24 - approx 3 13' 396 CABLE Y10 STEERING 13 YMM-22213-00-00
14' 427 CABLE Y10 STEERING 14 YMM-22214-00-00
The Y12 (or Y10 kit) is for smaller boats with engines below 15' 457 CABLE Y10 STEERING 15 YMM-22215-00-00
40kW (or below 55hp). Y24 can be applied if a simpler, more
conventional system is required.

Y11 STEERING CABLE (TO BE USED WITH Y12) Y21 STEERING CABLE (TO BE USED WITH Y22/Y23/
FEET CM Part Name Part Number Y24)
7' 213 CABLE Y11 STEERING 7 YMM-22007-00-00 FEET CM Part Name Part Number
8' 244 CABLE Y11 STEERING 8 YMM-22008-00-00 7' 213 CABLE Y21 STEERING 7 YMM-22107-00-00
9' 274 CABLE Y11 STEERING 9 YMM-22009-00-00 8' 244 CABLE Y21 STEERING 8 YMM-22108-00-00
10' 305 CABLE Y11 STEERING 10 YMM-22010-00-00 9' 274 CABLE Y21 STEERING 9 YMM-22109-00-00
11' 335 CABLE Y11 STEERING 11 YMM-22011-00-00 10' 305 CABLE Y21 STEERING 10 YMM-22110-00-00
12' 366 CABLE Y11 STEERING 12 YMM-22012-00-00 11' 335 CABLE Y21 STEERING 11 YMM-22111-00-00
13' 396 CABLE Y11 STEERING 13 YMM-22013-00-00 12' 366 CABLE Y21 STEERING 12 YMM-22112-00-00
14' 427 CABLE Y11 STEERING 14 YMM-22014-00-00 13' 396 CABLE Y21 STEERING 13 YMM-22113-00-00
15' 457 CABLE Y11 STEERING 15 YMM-22015-00-00 14' 427 CABLE Y21 STEERING 14 YMM-22114-00-00
16' 488 CABLE Y11 STEERING 16 YMM-22016-00-00 15' 457 CABLE Y21 STEERING 15 YMM-22115-00-00
17' 518 CABLE Y11 STEERING 17 YMM-22017-00-00 16' 488 CABLE Y21 STEERING 16 YMM-22116-00-00
18' 549 CABLE Y11 STEERING 18 YMM-22018-00-00 17' 518 CABLE Y21 STEERING 17 YMM-22117-00-00
20' 610 CABLE Y11 STEERING 20 YMM-22020-00-00 18' 549 CABLE Y21 STEERING 18 YMM-22118-00-00
19' 579 CABLE Y21 STEERING 19 YMM-22119-00-00
20' 610 CABLE Y21 STEERING 20 YMM-22120-00-00
21' 640 CABLE Y21 STEERING 21 YMM-22121-00-00
Y20 COMPLETE KIT FOR ALL ENGINES (IN- 22' 671 CABLE Y21 STEERING 22 YMM-22122-00-00
CLUDING Y21, Y22, Y25 AND STEERING WHEEL
YMM-24007-00-BK
FEET CM Part Name Part Number
10' 305 CABLE Y20 STEERING 10 YMM-22310-00-00 Y12 STEERING
11' 335 CABLE Y20 STEERING 11 YMM-22311-00-00 Part Name Part Number
12' 366 CABLE Y20 STEERING 12 YMM-22312-00-00 Y12 Helm/Bezel YMM-22400-00-00
13' 396 CABLE Y20 STEERING 13 YMM-22313-00-00 Y22 Helm (fast-connect system) YMM-22500-00-00
14' 427 CABLE Y20 STEERING 14 YMM-22314-00-00 Y23 Helm (non self-centring fast-connect) YMM-22500-10-00
15' 457 CABLE Y20 STEERING 15 YMM-22315-00-00 Y24 Helm/Bezel YMM-22510-00-00
16' 488 CABLE Y20 STEERING 16 YMM-22316-00-00 Y25 Bezel (90º version) YMM-22550-00-00
17' 518 CABLE Y20 STEERING 17 YMM-22317-00-00 Y25 Bezel (20º version) YMM-22551-00-00

2026 Marine Dealer Guide – 163
