Page 199 - Yamaha Marine Zubehoer 2026

Maintenance

300 HOURS SERVICE KIT
Part Number Description
6BTW006C0000 F30B F40F
6AKW006C0000 F40H F50H F60F
6CYW006C0000 F40G F70A
6HVW006C0000 F80D F100F
6EKW006C0000 F115B F130A
63PW006C0000 F150D F150F
6HPW006C0000 F150G F175A C F200F F200G
6ALW006C0000 F200C F225B
6CLW006C0000 F225F F250D F300B F225N F250N F300N
6GRW006C0100 F425A XF F375A XF
6MLW006C0000 F350N (6ML) 2024
6KNW006C0000 XF450 XF400

6BTW006C0000 6AKW006C0000
Part Number Description Qty Part Number Description Qty
5GH134409000 Element Assy, Oil Cleaner 1 5GH134409000 Element Assy, Oil Cleaner 1
62Y124140100 Thermostat Gasket 1 62Y124140100 Thermostat Gasket 1
66M124110100 Thermostat 1 63D443160000 GASKET, WATER PUMP 1
6D8245640000 ORing Fuel Filter 1 66M124110100 Thermostat 1
6D8WS24A0000 Fuel Filter 1 6D8245640000 ORing Fuel Filter 1
6H4443520200 Impeller 1 6D8WS24A0000 Fuel Filter 1
904300800300 Drain / Fill Gasket Geabox Oil 2 6H3443520000 Impeller 1
9043014M0900 Engine Oil Gasket 1 904300800300 Drain / Fill Gasket Geabox Oil 2
914903002500 Pin, Cotter 1 9043014M0900 Engine Oil Gasket 1
9321059MG700 ORing 1 914903002500 Pin, Cotter 1
947020041800 Plug, Spark NGK DPR6EB9 3 947020041800 Spark Plug NGK DPR6EB9 4

6CYW006C0000 6HVW006C0000
Part Number Description Qty Part Number Description Qty
5GH134409000 Element Assy, Oil Cleaner 1 5GH134407200 Element Assy, Oil Cleaner 1
62Y124140100 Thermostat Gasket 1 61A455380000 Spacer 1 1
66M124110100 Thermostat 1 6D8245640000 Gasket 1
6CJ443150000 GASKET, WATER PUMP 1 6D8WS24A0000 Element, Filter 1
6D8245640000 ORing Fuel Filter 1 6E5443520100 Impeller 1
6D8WS24A0000 Fuel Filter 1 6FP124110000 Thermostat 1
6H3443520000 Impeller 1 904300800300 Drain / Fill Gasket Geabox Oil 2
904300800300 Drain / Fill Gasket Geabox Oil 2 9043014M0900 Gasket 1
9043014M0900 Engine Oil Gasket 1 914904003000 Pin, Cotter 1
914903002500 Pin, Cotter 1 9321086M3800 ORing 1
947020042900 Plug, Spark NGK LKR7E 4 947020044000 Plug, Spark NGK LKR6E 9N 4

6EKW006C0000 63PW006C0000
Part Number Description Qty Part Number Description Qty
5GH134407200 Element Assy, Oil Cleaner 1 61A455380000 Spacer 1 1
61A455380000 Spacer 1 1 63P124140000 Gasket, Cover 1
6D8245640000 Gasket 1 67F124110100 Thermostat 1
6D8WS24A0000 Element, Filter 1 69J134400400 Element Assy, Oil Cleaner 1
6E5443520100 Impeller 1 6E5443520100 Impeller 1
6EK124110000 Thermostat 1 6P3245640000 Gasket 1
904300800300 Drain / Fill Gasket Geabox Oil 2 6P3WS24A0200 Element, Filter 1
9043014M0900 Gasket 1 904300800300 Drain / Fill Gasket Geabox Oil 2
914904003000 Pin, Cotter 1 9043014M0900 Gasket 1
9321086M3800 ORing 1 914904003000 Pin, Cotter 1
947020043700 Plug, Spark NGK LKR6E 4 9321086M3800 ORing 1
947020039100 Plug, Spark NGK LFR5A11 4

2026 Marine Dealer Guide – 197
