Other Rigging Components

BATTERY SWITCHES *NEW FOR 2026
These heavy-duty battery cut-off switch is designed for 12V DC and 24V DC electrical systems.The range supports a maximum cranking current of from
500-1000A 12V DC for up to 5 seconds and a continuous load current of 100A-450A 12V DC depending on the switches.
Compatibility: Suitable for all YAMAHA OE engines.
Description Part Number IP Rate Uni/Bi polar Max cranking Amp (CCA ) Max cont. Current
OB HEAVY DUTY SWITCH 100A 500A YME-HD500-A0-00 N/A Uni Polar 500 (12V) 100 (12V)
OB HEAVY DUTY SWITCH 100A 1000A YME-HD100-0A-00 N//A Uni Polar 1000 (12V) 100 (12V)
SPARE KEY 6FM-SSK00-00-0M N/A N/A N/A N/A
OB HD SWITCH 300A BLACK YME-HDSBL-C3-00 65 Uni Polar 1000 (12V) 300 (12V)
OB HD SWITCH 300A RED YME-HD300-A0-00 65 Uni Polar 1000 (12V) 300 (12V)
MASTER BATTERY SWITCH 450A YME-MBS25-00-00 65 Bi Polar 2500 (24V) 450 (24V)
OB MINI MASTER BATTERY SWITCH YME-MM300-A0 Uni Polar 1000 (12V) 300 (12V)
ELECTRICAL SWITCH BRACKET YME-ESB70-44-61 N/A N/A N/A N/A

Battery Chargers

Unique battery charging technology: Fully automatic switch mode charger that analyses the state of the battery, charges and
automatically switches to maintenance charging when ready. Includes battery testing, fault detection and float maintenance. Always
ensuring a full charge to prolong battery life time.
Designed for safety: Spark-free, protected from reverse polarity connections and short-circuit proof.
Light and compact: Easy to store and handle.
Yamaha Approved: Tested and approved by Yamaha service engineers to fit and work perfectly with the Yamaha Outboards range.
Quick connection: Combine it with YEC quick connectors - the Built-in Panel Plug, Charger Indicator and Indicator Panel 150 - for
reading the charge condition of your battery and/or for easier access between your Yamaha's battery and the YEC-9 or YEC-50
charger.

Battery Charger Part Number
1 - YEC-9: 6-step charger that can charge the battery of your Yamaha outboard. YME-YEC09-EU-20
2 - YEC-50: 8-step charger that can charge the battery of your Yamaha outboard. YME-YEC50-EU-20
3 - Flushmount charge indicator YME-YECIP-15-10
4 - Charge indicator cable YME-YECPL-05-10
1 2 3 4

BATTERY CHARGER CTEK CS ONE

Charger for all types of batteries. New durable design to make it easy to handle, with unique
mounting system on the back for quick connection to CS accessories. It can be left safely connected
for long periods during maintenance charging.

Recond option to restore and recondition lead-acid batteries. 12V supply to support the battery
during service work and retain contact power to the vehicle during battery replacement / removal.
Wake up option to revive seemingly dead lithium and lead-acid batteries. Advanced settings to
monitor charger voltage & amperage
Description Part Number
CTEK CS ONE EU YME-YEC01-EU-00
CTEK CS ONE UK YME-YEC01-UK-00

2026 Marine Dealer Guide – 175
