Page 49 - Yamaha Marine Marine Zubehör 2019
P. 49

Outboard Rigging & Accessories



       Other Rigging & Accessories





























                                            ANALOGUE GAUGE INTERFACE            ELECTRONIC COOLING WATER
       GATEWAY
                                            (AGI)                               PRESSURE SENSOR
       Enables simple connection of NMEA-   Enables simple connection of conventional   Enables the cooling water pressure to be
       compatible devices to the Yamaha Digital   analog gauges to the Yamaha Digital Network.   displayed on the 6Y8 tachometer and 6Y9
       Network. Multi-protocol for both 6Y8 and 6Y9   Multi-protocol both for both 6Y8 and 6Y9   colour display.
       connections.                         connections.
       Wire, lead  6YG-82521-00-00                                              F30 to F115  60V-8A4L0-1A-00
       Interface   6YG-8A2D0-00-00          6Y9-8A2D0-30-00                     F150 and up  69J-8A4L0-15-00















                                                                                TRANSOM MOUNTED
       ELECTRONIC SPEED SENSOR KIT          SPEEDOMETER TUBING
                                                                                MULTI-SENSOR
       Enables speed information to be displayed on   8 m  6Y5-83557-10-00      For 6Y9 Display  6Y9-83688-00-00
       the 6Y8 tachometer and 6Y9 colour display.  100 m   6Y5-83557-40-00      See page 85 for installation

       F30 to F300 (V6)  60V-8A4L1-1A-00


       BATTERY CABLE (FOR BATTERY           RECTIFIER/REGULATOR (F9,9L/
       CHARGING)                            FT9,9L)
       Allows electrical power to be drawn from   Allows to have stable DC current from the
       the engine. This battery cable is for battery   engine. Required for Electric Starter Kit
       charging only - not suitable for the starter   6DR-W8180-00-00 or individual battery cable
       motor. F9.9J/FT9.9L require a Rectifier/  68T-81949-00-00.
       Regulator.                                                               ELECTRIC STARTER KIT FOR F6A/
                                                                                F8/FT8/F9,9/FT9,9/F25G
       Description  Part No     QTY Price   Description  Part No    QTY  Price  Convert a manual start engine into electric
       Battery Cable  68T-81949-00-00 1     Rectifier/                          start. F25G M Model needs the rotor to be
       Fuse (10A-BL)  67F-82151-40-00 2     Regulator   68T-81960-00-00 1       replaced with a rotor with starter gear. F8F/
       Stay, Fuse Box 68T-82171-01-00 1     Assembly                            FT8G/F9,9J/FT9,9L/F25G require Rectifier/
       Puller, Fuse  67F-2812A-00-00 1      Bolt       97080-06012-00 1         Regulator.
       Washer      92990-06600-00  1        Clamp      90465-10098-00 2         F6A/F8C/FT8D  6DR-W8180-00-00*
                                                                                F8F/FT8G/F9,9J/  6DR-W8180-00-00*
                                                                                FT9,9L
                                                                                F25G          6FM-W8180-00-00*
                                                                                *kit with rectifier: 6DR-W8180-10-00
                                                                                                Marine accessories  –  47
