Outboard Rigging & Accessories

ENGINE FLUSH KIT
This extremely useful piece of equipment connects in seconds to your garden hose and allows you to
flush out harmful salt and sand. It can also be used for out-of-water operation for tune-ups.

For F4/F5/F6 engines ABB-FLUSH-JD-00
For F8 to F200 engines ABB-MOTOR-FL-SH

RIGGING HOSE
Keep your cables protected and uncluttered with a Rigging Hose. Yamaha Hoses are tough yet
flexible and are constructed from crush-resistant, UV-protected material to ensure a longer life span.
Hoses are mounted using a chromium-plated copper or plastic bracket and come in black, gray or
metallic blue colours.
Black 25ft/7,62m MAR-RIGHS-BK-25
Gray 25ft/7,62m ABB-RIGHS-GY-25
Metallic blue 25ft/7,62m ABB-RIGHS-BE-25
Black 2,5"/7m XTO MAR-RHS25-BK-25
White 2,5"/7m XTO MAR-RHS25-WT-25
RIGGING GROMMETS
These handy devices replace rubber engine grommets on bigger engines and provide positive
attachment without the need for clamps. They can be threaded directly onto one end of a rigging
hose with Transom Brackets at the other end.
115-250 (2-stroke) MAR-GROMM-ET-01
F150 MAR-GRMMT-F1-50
F200B/C-F250A/B MAR-GRMMT-LG-4S

TRANSOM FLANGE
Black 2,5"XTO MAR-TFLNG-25-BK
White 2,5" XTO MAR-TFLNG-25-WT

TRANSOM PLATES
Yamaha recommend these transom plates for boats with engines from 60hp and up.

V4/V6 engines aluminium 10mm YMM-09TP0-00-01
V8 engines aluminium 10mm YMM-09TP0-00-02

TRANSOM BRACKETS
The tough plastic bracket is easy to install by just threading the Rigging Hose onto it. It requires
no clamp, yet provides positive engagement. Use with the rigging Grommet on the other end for
quick, easy rigging. When the chromium plated copper ''through transom bracket'' is used, the
rigging hose is fitted with the clamp.

Chrome transom bracket with 2 anodised stainless steel clamps ABA-THRUT-RA-SM
Plastic transom bracket MAR-THRUT-RS-M2
TRANSOM BOLTS
Boat
Total Thread No Thread transom
Outboard Part Number Thread length length length thickness (*) Price
90101-12M51-00 M12 95mm 60mm 35mm
90101-12M65-00 M12 105mm 50mm 55mm
F25D - F300B 90101-12M03-00 M12 115mm 60mm 55mm 55-65mm
90101-12M05-00 M12 130mm 75mm 55mm 65-75mm
901-01120-47-00 M12 150mm 75mm 75mm 75-95mm
90101-12031-00(**) M12 150mm 75mm 75mm 75-95mm
F350A
90101-12036-00(**) M12 170mm 75mm 95mm 95-115mm
90101-12051-00 HS A4 BOLT (85MM)
90101-12055-00 HS A4 BOLT (200MM)
90101-12031-00 HS A4 BOLT (150MM)
90101-12053-00 HS A4 BOLT (110MM)
XTO
90101-12054-00 HS A4 BOLT (180MM)
90101-12036-00 HS A4 BOLT (170MM) *std
90101-12057-00 HS A4 BOLT (230MM)
90101-12056-00 HS A4 BOLT (210MM)
* Reference data ** High tension bolts for F350A
