Outboard Rigging & Accessories
MECHANICAL STEERING SYSTEMS
Y12 Helm/Bezel Y25 Bezel Y24 Helm/Bezel
Y22 Helm (fast-connect Y23 Helm (non self-
system) centring fast-connect
system)
All these systems are highly responsive and are designed and Y10 COMPLETE KIT FOR ENGINES BELOW 40KW
built to our exacting standards of safety, durability and comfort. (OR BELOW 55HP) INCLUDING Y11, Y12 AND
The Y22 and Y23 helms (or Y20 kit) can be used for all types
of applications. Our Y23 helm has a special non self-centring STEERING WHEEL YMM-24003-00-BK
mechanism, which means the wheel won’t return automatically FEET CM Part Number Part Name Price
to the straight ahead position after a turn. Both these helms
have to be installed with a Y25 Bezel, which is available in 20° and 8’ 244 YMM-22208-00-00 CABLE Y10 STEERING 8
90° versions. 9’ 274 YMM-22209-00-00 CABLE Y10 STEERING 9
10’ 305 YMM-22210-00-00 CABLE Y10 STEERING 10
Number of turns lock-to-lock: Y12 - approx 2.5 Y22/Y23 - 11’ 335 YMM-22211-00-00 CABLE Y10 STEERING 11
approx 3.8 Y24 - approx 3 12’ 366 YMM-22212-00-00 CABLE Y10 STEERING 12
13’ 396 YMM-22213-00-00 CABLE Y10 STEERING 13
The Y12 (or Y10 kit) is for smaller boats with engines below 14’ 427 YMM-22214-00-00 CABLE Y10 STEERING 14
40kW (or below 55hp). Y24 can be applied if a simpler, more 15’ 457 YMM-22215-00-00 CABLE Y10 STEERING 15
conventional system is required.
Y11 STEERING CABLE (TO BE USED WITH Y12)
Part Name Part Number Price FEET CM Part Number Part Name Price
Y12 Helm/Bezel YMM-22400-00-00 7' 213 YMM-22007-00-00 CABLE Y11 STEERING 7
Y22 Helm (fast-connect system) YMM-22500-00-00 8' 244 YMM-22008-00-00 CABLE Y11 STEERING 8
Y23 Helm (non self-centring fast-connect) YMM-22500-10-00 9' 274 YMM-22009-00-00 CABLE Y11 STEERING 9
Y24 Helm/Bezel YMM-22510-00-00 10' 305 YMM-22010-00-00 CABLE Y11 STEERING 10
Y25 Bezel (90º version) YMM-22550-00-00 11' 335 YMM-22011-00-00 CABLE Y11 STEERING 11
12' 366 YMM-22012-00-00 CABLE Y11 STEERING 12
13' 396 YMM-22013-00-00 CABLE Y11 STEERING 13
14' 427 YMM-22014-00-00 CABLE Y11 STEERING 14
15' 457 YMM-22015-00-00 CABLE Y11 STEERING 15
16' 488 YMM-22016-00-00 CABLE Y11 STEERING 16
17' 518 YMM-22017-00-00 CABLE Y11 STEERING 17
18' 549 YMM-22018-00-00 CABLE Y11 STEERING 18
20' 610 YMM-22020-00-00 CABLE Y11 STEERING 20
